Name: Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder
Brand: Airwolf Automation
SKU: MCJA-11-12-25, MCJA-11-12-30, MCJA-11-16-5, MCJA-11-16-10
Price: 34.00 USD
Availability: InStock

Nhà Sản phẩm Khí nén Air xi lanh

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Thông tin chi tiết sản phẩm:

Nguồn gốc:	Đài Loan, Trung Quốc
Hàng hiệu:	Mindman, AIRWOLF or OEM
Chứng nhận:	CE, ISO9001
Số mô hình:	MCJA-11-12-25, MCJA-11-12-30, MCJA-11-16-5, MCJA-11-16-10

Thanh toán:

Số lượng đặt hàng tối thiểu:	1 mảnh
Giá bán:	5-63USD
chi tiết đóng gói:	Hộp, Thùng, Pallet, Túi Nhựa
Thời gian giao hàng:	1-7 ngày làm việc
Điều khoản thanh toán:	T/T, Công Đoàn Phương Tây, PayPal
Khả năng cung cấp:	1000 chiếc mỗi tuần

Tiếp xúc

Chi tiết sản phẩm

Mã mặt hàng:	MCJA-11-12-25, MCJA-11-12-30, MCJA-11-16-5, MCJA-11-16-10	Chất liệu thân máy:	Hợp kim nhôm
Vật liệu đóng gói Piston:	NBR	Áp suất làm việc:	0,05 ~ 1MPa
Nhiệt độ hoạt động:	-5~+60oC(Không đóng băng)	Phương tiện làm việc:	Không khí
Kích thước lỗ khoan:	12, 16mm	Chức năng:	Hành động kép
Làm nổi bật:	Double acting compact air cylinder , Pneumatic compact cylinder with warranty , MCJA series double acting cylinder

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Built from carefully selected aluminum alloy with hard-anodized treatment, the MCJA body resists wear and corrosion in continuous-duty pneumatic systems, while the extruded profile integrates a peripheral sensor groove that lets proximity switches mount flush and adjust position without external brackets. Installation relies on countersunk-hole tooth mounting, so the cylinder sits directly against the fixture without extra foot brackets, cutting parts count and keeping the envelope tight around the actuator itself.

Order Codes:

Item Code	Piston (mm)	Stroke (mm)	Type
MCJA-11-12-25	12	25	Double acting
MCJA-11-12-30	12	30	Double acting
MCJA-11-16-5	16	5	Double acting
MCJA-11-16-10	16	10	Double acting

Specification:

Model		MCJA
Acting type		Double acting / Single acting							Double acting
Tube I.D. (mm)		12	16	20	25	32	40	50	63	80	100
Port size		M5×0.8				Rc1/8		Rc1/4			Rc3/8
Medium		Air
Operatingperssurerange (MPa)	Double acting	0.05~1		0.03~1		0.02~1
	Single acting	0.2~1		0.15~1		0.1~1			—
Proof pressure		1.5 MPa
Ambient temperature		-5°C~+60°C (No freezing)
Available speed range		50~500 mm/sec

Material:

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Dimensions:

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder
